APR-SC-230V-1C Slim Röle

  PDF İndir
  Teklif İste
Ürün Açıklaması
Ürün Açıklaması
Power Load A 6
VAC 250
lnput Voltage VAC/DC 230
Dielectric Strength V/min 4000VAC V/S Coil/Contact
2500VAC V/S BetweenContacts
Screw Torque Nm 0.8-1.0
Size Of Wire AWG/mm2 20-14/0.5-2.5
Temperature Range oc -35 -    + 70
Net Weight g 28.6
Contact Resistance mO <50m0
lnsulation Resistance mO >100m0 (500VDC Tramegger)
Plug Durability Times 10000 (Cycles)
ROHS Compliance I ROHS
Flame Retardant I Ul94-V1
Shell Plastic I PA6-G30F
lnsert Material I High precision phosphor copper The surface of the tin plating
